Cascade IOMAX is a robust IONM system designed to withstand the environmental hazards of the operating room

The modular design of Cascade IOMAX allows users to tailor their IONM setup to the specific requirements of each surgery. The comprehensive design of the IOMAX with Cascade Surgical Studio software provides seamless multi-modality monitoring, captures critical information, delivers clinical excellence and strengthens documentation.

Flexible channel configurations cover the needs of every procedure type from ENT and orthopedic spine to more complex neurosurgery cases. Cortical and Limb Modules are waterproof and drop-tested with durable rubber bumpers.

Request a demo to see it in action:

Cascade IOMAX

The IOMAX Cortical Module is designed for close proximity to the patient’s head

Use the Cortical Module solo, or combine it with up to four Limb Modules. Configure the IOMAX system from eight to 80 channels. The Cortical Module features:

  • 16 recording channels
  • TCS-9 for dynamic montaging of transcortical MEPs
  • Low Current stimulation
  • Auditory stimulation
  • Visual stimulation
IOMAX Base Unit with End View

IOMAX Base Module provides power and communication

…via a single SafeT™ Cable to the modules at the OR table, and allows Trigger In/Out interfacing with third-party devices.

IOMAX Limb Module

The IOMAX Limb Module is designed for recording and stimulating the arms and legs

Use one or two Limb Modules independently, or combine one to four Limb Modules with the Cortical Module. Each IOMAX Limb Module offers eight recording channels, five paired E-Stim outputs, SpO2, and heart rate.

Cascade IOMAX 32-Channel Amplifier

The new IOMAX 32-channel amplifier records EEG and direct cortical SSEPs

The IOMAX 32-channel amplifier can be added to any existing IOMAX configuration, or connected directly to the IOMAX Base Module.

LCSwap

LCSwap is a comprehensive switch matrix solution for direct cortical stimulation

Twelve outputs can be independently assigned as anode or cathode; it also includes two paired outputs for hand-held probes.

A single cable connects IOMAX at the operating table to the surgical monitoring technologist station

SafeT™ cables are durable and waterproof, with quick-release metal color-coded connectors. These cables are completely interchangeable between Cortical and Limb Modules and the 32-channel amplifier.

How does IOMAX fit in your OR?

Cascade Surgical Studio (CSS) Software
An intuitive and thoughtful user interface

Streamline your workflow, deliver clinical excellence, capture critical information, monitor all modalities, strengthen documentation, and stay connected.

logo for cadx surgical simulator

CadX Surgical Simulator
Learn IONM outside of the OR

Manipulate the patient control panel to create real-world scenarios for demonstration or assessment purposes. Simulate realistic data demonstrating anesthesia, technical setup, trace characteristics, surgical effects, pedicle screw, and scripts.

Cadwell’s C2 Cart is specifically developed and optimized for Cascade IOMAX and IONM applications

  • Small footprint for tight spaces in the OR
  • Height adjustment for user comfort while sitting or standing
  • Module storage
  • Cable management system
  • Telescopic camera mount
  • Second monitor mount that swivels for surgeon view
  • Large 5” (12.7 cm) wheels for easier maneuverability and directionally lock for better control during transport
  • Bin and basket features for storage of electrodes, supplies, and accessories
  • Optional wall-mounted computers and modules can also save space in an operating room
C2-carts-IOMAX

Shop estore.cadwell.com for a complete line of IONM electrodes, accessories, and consumables

Cadwell offers a complete line of IONM electrodes, lead wires, probes and stimulators at estore.cadwell.com (USA customers). We continuously innovate and release new consumables that our customers need and use. Check out our Supplies and Accessories Product Catalog.

International Customers: Some products may not be available in all countries and markets; check availability with your Cadwell distributor.

IONM Electrodes

Purchase IONM electrodes at the Cadwell estore

Shop Cadwell’s e-store for a large selection of high quality needles that meet all of your IONM subdermal needle needs, including cork screw, parallel paired, bent, twisted, singles, and ENT needles.

IONM Probes

Purchase IONM probes at the Cadwell estore

Cadwell offers a vast disposable probe portfolio for IONM and stimulating for a variety of procedures, including monopolar, concentric, bi-polar, bent, and flush tip stimulating probes.

Specialty IONM Supplies

Purchase IONM supplies and accessories at the Cadwell estore

Cadwell offers a suite of IONM specialty electrodes, including endotracheal tubes, laryngeal surface electrodes, subdural strips, epidural spinal electrodes, Cadwell Clip-On Plungers and our patented Multi-Stage Clip.
